| Basic Information | |
| Supported CPU | LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core, Pentium Gold and Celeron Processors L3 cache varies with CPU (Please refer "CPU Support List" for more information.) |
| Chipset | Intel H610 Express Chipset |
| BIOS | 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Form Factor | Micro ATX Form Factor; 23.0cm x 21.5cm |
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out |
| Expansion Slots | |
| PCI | CPU: - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 Chipset: - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
| Memory | |
| Type | DDR5 |
| Slots | 2 x DIMM sockets |
| Supported Memory | Support for 5600/5200/4800/4400 MT/s memory modules 13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors: 4800/4400 MT/s memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memor |
| Maximum Memory | Supporting up to 128 GB (64 GB single DIMM capacity) of system memory |
| Graphics | |
| Graphics | Integrated Graphics Processor-Intel HD Graphics support: - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support native HDMI 2.1 TMDS compatible ports. - 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 (Graphics specifications may vary depending on CPU support.) |
| Connector & Ports | |
| HDMI | 1 x HDMI port |
| Display Port (s) | 1 x DisplayPort |
| USB (s) | Chipset: - 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) - 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) |
| LAN Port (s) | Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) |
| Supported Storage | Chipset: - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 3.0 x4/x2 SSD support) - 2 x SATA 6Gb/s connectors |
| Internal I/O Ports | Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 2 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x Clear CMOS jumper Back Panel Connectors 1 x HDMI port 1 x DisplayPort 2 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) |
| Others | |
| Special Features | iTE I/O Controller Chip Bundled Software Norton Internet Security (OEM version) LAN bandwidth management software |
| Warranty Information | |
| Warranty | 03 Years |
The GIGABYTE H610M K DDR5 Micro ATX Motherboard price in bd offers an exceptional foundation for building modern Intel-based PCs. Compatible with 14th, 13th, and 12th Generation Intel® Core, Pentium Gold, and Celeron processors, this motherboard ensures reliable performance with its Intel H610 Express Chipset. With support for DDR5 memory up to 128 GB, it delivers fast and efficient multitasking, perfect for gaming, office productivity, or multimedia workloads. Integrated Intel HD Graphics provides high-quality visuals through HDMI 2.1 and DisplayPort 1.2, supporting resolutions up to 4K.This Micro ATX motherboard features multiple expansion options including PCIe 4.0 x16 and PCIe 3.0 x1 slots, enabling you to install graphics cards, storage controllers, or additional peripherals easily. It also includes advanced connectivity options like USB 3.2 Gen 1, USB 2.0, and Realtek GbE LAN for high-speed network performance. Audio enthusiasts will appreciate the Realtek High Definition Audio supporting 2/4/5.1/7.1-channel setups, configurable through bundled software.For storage, the motherboard offers one M.2 slot for NVMe SSDs and two SATA 6Gb/s connectors, ensuring flexible and fast storage solutions. Built with durability in mind, it includes features like an iTE I/O controller chip, TPM header for enhanced security, and a 3-year manufacturing warranty. Whether upgrading your current setup or building a new PC, the GIGABYTE H610M K DDR5 Micro ATX Motherboard provides a stable, efficient, and future-ready platform.
